Mosaic Glass Production Line

This production line including glass washing machine,glass printing machine,glass drying machine,glass cutting machine,glass press machine,glass stacking machine,glass oven .,etc
Availability:
Quantity:

快速磨边机

Mosaic glass production line


For the process,please check as followed,we will explain to you step by step:

1. Wash the glass sheet with the wahsing machine( glass sheet size is about 500*500mm-600*600mm)
2,then pass the clean glass sheet to the printing machine to print the color (pigment+printing ink).
3,dried the colored glass sheet, then print the glass sheet again with the white back coat powder(to cove the pigment color) by the printing machine again, and wait the glass sheet dry.
4,After the glass sheet is dried, then use the glass cutting machine to cut the glass sheet  then use the plier to break the glass strips and put the glass strips onto the glass breaking machine to break and get the 10*10mm/15*15mm/20*20mm and other glass mosaic chips.
5.After you get the glass chips, then you should put the glass chips onto the glass kiln to fire, the temperature in the kiln is about 700-850 degrees. After the firing, you will get th
e round melted glass mosic chips.
6.Then you mount the melted glass chips with the mounting mold,you use the backing mesh and glue to stick the glass chips into total sheet.  then you can pack and ship to clients.
     3   2    5

And the ration between the glass printing ink and the pigment &toner mixture powder is about 1:2, it means when you use 1kg printing ink, you can mix around 2 kgs' powder together, then use the printing machine to print the color.   And the ratio is the same 2:1 for the white back coat powder with the printing ink to cover the back surface of the mosaic tile.
For the glass mosaic color, you can adjust the pigment's quantity to control the color, when you add more pigment and less toner, then the color will be dark. when you add less pigment and more white toner, then the color will be light.

公司简介

*20years factory production experience*3 years machine warranty

*156 exported country experience

*20000 square meters Glass machine&upvc windows machine factory


*Shandong Eworld Machine Co., Ltd.


Shandong Eworld Machine Co., Ltd. is one of the famous and big manufacturers of glass equipment, windows equipment, CNC equipment.
Since its inception in 2002, and after many years of development and growth, the company is now playing a leading role in glass machinery and windows door machine inChina Eworld group has 2 factories, which are located in Jinan City. Advanced products, exquisite techniques, solid working, and cordial services

埃瓦德工厂大门

工厂证书

About glass deep processing machines, we are professional and have full set certificates.For every glass cutting      machine, we have
serious quality control for every machine and every parts before it leaves our factory.

展会

We went to many exhibitions in China to expand our reputation.

合影

Welcome to visit our factory!If you have plan to come to China and see our machines, please contact us at least 15 days in advance
then we can arrange our
schedule and arrange to treat you.
No matter which transport method you choose, we will pick up you.
If you have any questions, please feel free to contact us.
24*7, we always be here !

运输售后

FAQ


Question:Are you manufacture?

Answer:Yes,we are the professional manufacture which have more than 5 workshops.


Question: How about the service ?

Answer:

1).reply it at once if from Ali-trademanager,if by email,it reply it within 12 hour

2).deliver max. days within 15 days

3).24 hours for after -sale serive

4).more than 12 years experience in this kind machine field

5).fluent english ,communication barrier free


Question:What’s the guarantee ?

Answer:

1).Our guarantee for 18 months.

2).24 hour’s technical support by email or calling

3).English manual and video tutorial

4).2 year quality guaranty for the machine (excluding the consumables)

5).We will provide the consumable parts at an agency price

6).24 hours on line service each day, free technical support.


Q: Do you provide equipment operation training?

Answer:Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. Allof our engineers have passport.


Question:if our price is higher than another company or factories ?

Answer:please check, what is is the different of the machine parts ,service and guarantee,especially the machine inner electric parts,sometimes, if machines have breakdown, the most reason is the machine inner electric parts problem, but we use the famous andreliable parts for the machines inside.


Question:How long is the delivery time ?

Answer:For standard machines, it would be 3-15 days; For non-standard machines and customized machines according to clients specific requirements, it would be 15 to 30 days.


Question: What is the payment ?

Answer:Any payment method you want,such as L/C,T/T,D/P,West-union and so on.
