Arc Glass Round Glass Cutting Machine

Arc Glass Round Glass Cutting Machine,Owing to our industrial expertise accumulated over time, we have established ourselves as a leading Manufacturer, Supplier and Exporter in the industry. We offer Mini Glass Cutting Machine to our esteemed customers at attractive price. The machine boasts striking features such as light weight, strong built and durability. Our excellent distribution system enables you to get it delivered to your doorstep in no time at affordable prices.

Quantity:
  • NC1313
  • Eworld

Round Arc Glass Cutting Machine


Multi Head Automatic Straigt Line Glass Cutting Machine

Owing to our industrial expertise accumulated over time, we have established ourselves as a leading Manufacturer, Supplier and Exporter in the industry. We offer Arc Glass Round Glass Cutting Machine to our esteemed customers at attractive price. The machine boasts striking features such as light weight, strong built and durability. Our excellent distribution system enables you to get it delivered to your doorstep in no time at affordable prices.

Introduction :  Work flow- After starting the inputting machine, arms automatically suck glass from the shelf. Under sensor controlled, glass automatically finds glass edge in the X and Y directions. After moving glass sheets to designated location, transport glass to the automatic cutting table. Cutter will move to coordinate origin, and automatically start to cut according to the preinstall graph.
The operator can edit the glass size for cutting with computer. The computer can optimize the cutting size, and give out the data for processing.

Features :

  • Bed using thick wall pipe welding and become, the high temperature tempering treatment, ensure that the deformation is small, rigid good, the intensity is big.

  • The X, Y axis adopt reliable motor drive, selected pairing, ensure the smooth movement.

  • Using high precision level gear rack drive, high precision, speed and strength.

  • Adopts imported linear guide square, high precision, long life.

  • Mechanical and electrical full excellent design, selection of all kinds of electrical accessories, the failure rate drop

  • Software compatibility- compatible type3 / Artcam/Castmate/wentai and so on the many kinds of CAD/CAM design software.

  • Performance worry about- a breakpoint renewal carving, power off recovery, processing time prediction, and other functions, the real human nature design.


Machine details :

  • Software- Ncstudio,Wenta

  • English instruction about manual guide, how to install machine

  • AC stepper motor- 4 pcs( 850 W from Jiangsu

  • Vacuum- 1kw,Blower- 2KW

  • Cutting head- Auto oil

  • Rack/Guides- reliable brand in china

  • CAD Designed graph and figure, all cutting are fully automatic

  • The tabletop- The smoothness±0.2mm/m


Multi Head Automatic Straigt Line Glass Cutting Machine

Details

Working size1300*1300mm
Cutting thickness1-12mm
Table size1500*1700mm
Cutting speed20m/min
Machine bedSteel lathe bed
X-Y-Z movementImported gear rack
Working accuracy≤±0.15mm/m
Repositioning accuracy≤±0.15mm/m
Driver motorsstepper
Working voltageAC 220V
Total power4 KW
Command codeG code*uoo,*mmg,*plt
SoftwareArtcam,Wenta
Computer systemWindows 98/2000/XP/Win7
controlNc Studio
Oil lubrication systemAutomatic
Table surfacebakelite plate
Packing size1670*1870*1780mm
Weight600KGS
