Screen Printing Machine for Non-Woven Fabric

Screen Printing Machine for Non-Woven Fabric are widely used in the electronics, advertising, package printing, sports equipment, toys, stationary gifts, metal processing industries.

silk screen printing machine suitable for printing on all kinds of flat materials, print on metal, glass, wood, paper, plastics, membranes switch, PCB, PET heating transfer film,tempered glass,auto windshield,light guide plate,DC card,nameplate ,also printing on bags,non-woven fabrics, ceramic decals, glazing plate glass, label and panel , refrigerator and air-conditioner decals,plastic sheet, and other products with the material of PVC, which have high requirement in overprinting.

Quantity:
  • SD6090
  • Eworld

Screen Printing Machine for Non-Woven Fabric

QQ图片20170114143830_副本

Application:



Screen Printing Machine for Non-Woven Fabric are widely used in the electronics, advertising, package printing, sports equipment, toys, stationary gifts, metal processing industries.



silk screen printing machine suitable for printing on all kinds of flat materials, print on metal, glass, wood, paper, plastics, membranes switch, PCB, PET heating transfer film,tempered glass,auto windshield,light guide plate,DC card,nameplate ,also printing on bags,non-woven fabrics, ceramic decals, glazing plate glass, label and panel , refrigerator and air-conditioner decals,plastic sheet, and other products with the material of  PVC, which have high requirement in overprinting.

 Accessories:



Toolbox

six-angle-wrench, screwdriver, activity-wrench, manual, protective tube

1pcs/each

scraper and scraping blade rubber strip

600mm

1set

scraper and scraping blade

900mm

1set

Air tube

Φ8

5m

Power outlet


1pcs

Screen Printing Machine for Non-Woven Fabric

technical parameters:



Model

SD-6090

SD-7010

SD-9012

Workbench Area (mm²)

720×1000

800×1100

1000×1300

Max Print Area (mm²)

600×900

700×1000

900×1200

Max Screen Size(mm)

900×1200

1000×1300

1200×1500

Min Screen Size(mm)

450×550

550×650

650×700

Frame Lift Height (mm)

300

300

300

Operation Air Pressure (Mpa)

0.3-0.5

0.3-0.5

0.3-0.5

Air-Consumption(0.6Mpa)(L/pcs)

13

13

13

Source Power (kw)

2.3

2.3

3.7

Rated Power (V/Hz)

220/50

220/50

380/50

Max Table Height(to floor)

820mm

820mm

820mm

Printing Speed (pcs/h)

500-1200

500-1200

400-1000

Dimension (mm) L×W×H

1500×1200×1250

1600×1350×1280

1800×1400×1300

Weight (kg)

410

480

550

Thickness of printing stock

0-20mm,0-50mm

0-20mm,0-50mm

0-20mm,0-50mm
