Small Size Automatic Glass Cutting Machine

Owing to our industrial expertise accumulated over time, we have established ourselves as a leading Manufacturer, Supplier and Exporter in the industry. We offer Mini Glass Cutting Machine to our esteemed customers at attractive price. The machine boasts striking features such as light weight, strong built and durability. Our excellent distribution system enables you to get it delivered to your doorstep in no time at affordable prices.
Availability:
Quantity:
  • NC6090

  • Eworld

NC玻璃切割机Overview


Quick Details

Applicable Industries: Manufacturing Plant

After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service

Local Service Location: None

Showroom Location: None

Condition: New

Machine Type: Glass Cutting Machine

Production Capacity: 30Sets/Month

Place of Origin: Shandong, China

Brand Name: Eworld Machine

Voltage: 380v Or 110v Or As request

Power: 6kw

Dimension(L*W*H): 1470*1370*1780mm

Weight: 500KG

Certification: CE&ISO

Warranty: 1 Year

After-sales Service Provided: Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support

Key Selling Points: Easy to Operate

Glass Thickness: 1-40mm

Machinery Test Report: Provided

Video outgoing inspection: Provided

Marketing Type: Ordinary Product

Warranty of core components: 1 Year

Core Components: Pressure vessel, Motor, Bearing, Gear, PLC, Pump, Engine, Gearbox

Product name: Laminated glass and thick glass cutting machine

Usage: Cut glass

Table size: Accept the custom made

Min glass size: No limited

Cutting accuracy: from -0.15 to _0.15

Keyword: High Precision

Seaport: Qingdao Port

Glass thickness: 3-50mm

Automatic range: NC computer controlled

Material: Stainless Steel


Supply Ability

Supply Ability: 3 Set/Sets per Month


Packaging & Delivery

Packaging Details: Wooden Case Seaworthy Package

Port: Qingdao Port Or China Main Port

Picture Example:


Lead Time:


Quantity(Sets) 1-1 >1
Est. Time(days) 30 To be negotiated


Product Description


Brief introduction:


Introduction:

1) Workflow: After starting the inputting machine, arms automatically suck glass from the shelf. Under sensor-controlled, glass automatically finds the glass edge in the X and Y directions. After moving glass sheets to the designated location, transport glass to the automatic cutting table. Cutter will move to coordinate origin, and automatically start to cut according to the preinstall graph.

2) The operator can edit the glass size for cutting with the computer. The computer can optimize the cutting size, and give out the data for processing.

  38 拷贝      DSC09425

Feature

1. Bed using thick wall pipe welding and become the high-temperature tempering treatment, ensure that the deformation is small, rigid good, the intensity is big.

2. The X, Y-axis adopt reliable motor drive, selected pairing, ensure smooth movement.

3. Using high precision level gear rack drive, high precision, speed, and strength.

4. Adopts imported linear guide square, high precision, long life.

5. Mechanical and electrical full excellent design, selection of all kinds of electrical accessories, the failure rate drop.

6. Software compatibility: compatible type3 / Artcam/Castmate/wentai and so on the many kinds of CAD/CAM design software.

7. Performance worry about: a breakpoint renewal carving, power-off recovery, processing time prediction, and other functions, the real human nature design.


Machine details:


Equipment:

1. Software: Ncstudio, Wenta

2. English instruction about the manual guide, how to install the machine

3. AC stepper motor: 4 pcs( 850 W) from Jiangsu

4. Vacuum: 1kw, Blower: 2KW

5. Cutting head: Auto oil

6. Rack/Guides: reliable brand in china

7. CAD-Designed graph and figure, all cutting are fully automatic

8. The tabletop: The smoothness≤±0.2mm/m


1 Working size 800*800mm
2 Cutting thickness 1-19mm
3 Table size 900*1100mm
4
Cutting speed 20m/min
5 Machine bed Steel lathe bed
6 X-Y-Z movement Imported gear rack
7 Working accuracy ≤±0.15mm/m
8 Repositioning accuracy ≤±0.15mm/m
9 Driver motors Stepper
10 Working voltage AC 220V
11 Total power 6 KW
12 Command code G code*uoo,*mmg,*plt
13 Software Artcam,Wenta
14 Computer system Windows 98/2000/XP/Win7
15 Control Nc Studio
16 Oil lubrication system Automatic
17 Table surface Bakelite plate
18 Packing size 1470*1370*1780mm
19 Weight 500KGS


The samples

 NC Automatic Multi Heads Glass Cutting Machine For Shaped Glass Accept Custom Made    NC Automatic Multi Heads Glass Cutting Machine For Shaped Glass Accept Custom Made    NC Automatic Multi Heads Glass Cutting Machine For Shaped Glass Accept Custom Made


2620-有皮带3

*20years factory production experience*3 years machine warranty

*156 exported country experience

*20000 square meters Glass machine&upvc windows machine factory

*Shandong Eworld Machine Co., Ltd.


Shandong Eworld Machine Co., Ltd. is one of the famous and big manufacturers of glass equipment, windows equipment, CNC equipment.
Since its inception in 2002, and after many years of development and growth, the company is now playing a leading role in glass machinery and windows door machine inChina Eworld group has 2 factories, which are located in Jinan City. Advanced products, exquisite techniques, solid working, and cordial services

埃瓦德工厂大门

2620-有皮带42620-有皮带5

About glass deep processing machines, we are professional and have full set certificates.For every glass cutting machine, we have
serious quality control for every machine and every parts before it leaves our factory.

2620-有皮带6

We went to many exhibitions in China to expand our reputation.

2620-有皮带7

Welcome to visit our factory!If you have plan to come to China and see our machines, please contact us at least 15 days in advance
then we can arrange our
schedule and arrange to treat you.
No matter which transport method you choose, we will pick up you.
If you have any questions, please feel free to contact us.
24*7, we always be here !

2620-有皮带8

FAQ

Question:Are you manufacture?

Answer:Yes,we are the professional manufacture which have more than 5 workshops.


Question: How about the service ?

Answer:

1).reply it at once if from Ali-trademanager,if by email,it reply it within 12 hour

2).deliver max. days within 15 days

3).24 hours for after -sale serive

4).more than 12 years experience in this kind machine field

5).fluent english ,communication barrier free


Question:What’s the guarantee ?

Answer:

1).Our guarantee for 18 months.

2).24 hour’s technical support by email or calling

3).English manual and video tutorial

4).2 year quality guaranty for the machine (excluding the consumables)

5).We will provide the consumable parts at an agency price

6).24 hours on line service each day, free technical support.


Q: Do you provide equipment operation training?

Answer:Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. Allof our engineers have passport.


Question:if our price is higher than another company or factories ?

Answer:please check, what is is the different of the machine parts ,service and guarantee,especially the machine inner electric parts,sometimes, if machines have breakdown, the most reason is the machine inner electric parts problem, but we use the famous andreliable parts for the machines inside.


Question:How long is the delivery time ?

Answer:For standard machines, it would be 3-15 days; For non-standard machines and customized machines according to clients specific requirements, it would be 15 to 30 days.


Question: What is the payment ?

Answer:Any payment method you want,such as L/C,T/T,D/P,West-union and so on.




Our Goal

Eworld Machine provides full set services and high-quality but low-price products. We are always looking for long-term cooperation, not a one-time deal.


Pre-sale

Eworld provides 24 hours high-quality service. When clients contact Eworld and ask for products, E-World answers at once, except our clerk's sleep, which condition we answer within 10hours. Eworld understands how important it is for the customers to choose a suitable machine, we are ready to come up with the best solution for customers.


On-sale

For all your requests, we will supply the best solution to you as soon as possible. If you have any inquiries or problems, please contact us with E-mail, skype, Alibaba, WhatsApp, phone, etc.


Eworld welcome customers to visit the factory, we will pick you up from the airport or train station. Eworld location is convenient to welcome clients because of next to the train station.


After-sale service

When customers buy the glass processing machine, E-World promises that the machine will be delivered in 20-25 days after deposit. E-World arranges commodity packages suitable for the shipment of sea. E-World provides English instruction about manual guides and video technical support. Any problems please let us know, and we will give you detailed supports and advice. E-World promises worry-free repair of one whole year after installation, the original fault parts damaged, be free of any charges. When a serious breakdown and big fault happens, E-World has engineered and they can fly to there to solve it.
