EWC-2516
EWORLD
This Home Textiles Materials Cutting Machine is a CNC oscillating vibrating digital knife cutting machine suitable for precision cutting of soft household materials such as household soft, printed carpets, table mats, curtains, etc.
This cutting machine not only has the characteristics of fast cutting speed, high cutting precision, neat and beautiful cutting edges, smoke-free, pollution-free, energy saving and environmental protection, but also provide you with the correct cutting technology for your specific application. Help maximize material utilization and minimize labor requ
FUNCTION FEATURES
1.Can cut any kind fabric with smooth sealing cutting edge.
2.Can cut serval layers fabric.
Best choice for cutting zebra blind and Shangri-la blind fabric.
3.Using H.H.S blade for duable cutting
4.High accuracy output,min cutting width 3mm
5.Electric rolling fabric roll feeding,easy to feed fabric
6.Machine body made of aluminum profile
7.Optional: working table with measuing back stop
Model | EWC-2516 | EWC-3020 | EWC-2525 | EWC-2530 |
Working Area | 2500*1600mm | 3000*2000mm | 2500*2500mm | 3000*2500mm |
Cutting Thickness | 0.1mm-25.0mm | |||
Max. Cutting Speed | 1200mm/s | |||
Cutting Tolerance | ±0.1mm | |||
Rated power | 11KW | |||
Supported Format | DXF, PLT, and More | |||
Transmission Interface | Ethernet | |||
Fixed Mode | Vacuum Absorb | |||
Recommended Configuration | Driven Rotary Cutting Tool,Punching Tool(V-shape or Circle Shape),Drawing Tool,CCD Camera,Scanner,Cradle(Auto or Normal), Package Box. | |||
Operation Properties | Continuous Cutting with High Efficiency;7*24 with Zero Downtime. | |||
Materials Available For Cutting | Soft fabric, PVC coil floor mat Cutting, printed carpet, leather, soft glass tablecloth, etc. | |||
Supply voltage | AC110V/220V/380V±10%, 50HZ/60HZ, customized. | |||
This Home Textiles Materials Cutting Machine is a CNC oscillating vibrating digital knife cutting machine suitable for precision cutting of soft household materials such as household soft, printed carpets, table mats, curtains, etc.
This cutting machine not only has the characteristics of fast cutting speed, high cutting precision, neat and beautiful cutting edges, smoke-free, pollution-free, energy saving and environmental protection, but also provide you with the correct cutting technology for your specific application. Help maximize material utilization and minimize labor requ
FUNCTION FEATURES
1.Can cut any kind fabric with smooth sealing cutting edge.
2.Can cut serval layers fabric.
Best choice for cutting zebra blind and Shangri-la blind fabric.
3.Using H.H.S blade for duable cutting
4.High accuracy output,min cutting width 3mm
5.Electric rolling fabric roll feeding,easy to feed fabric
6.Machine body made of aluminum profile
7.Optional: working table with measuing back stop
Model | EWC-2516 | EWC-3020 | EWC-2525 | EWC-2530 |
Working Area | 2500*1600mm | 3000*2000mm | 2500*2500mm | 3000*2500mm |
Cutting Thickness | 0.1mm-25.0mm | |||
Max. Cutting Speed | 1200mm/s | |||
Cutting Tolerance | ±0.1mm | |||
Rated power | 11KW | |||
Supported Format | DXF, PLT, and More | |||
Transmission Interface | Ethernet | |||
Fixed Mode | Vacuum Absorb | |||
Recommended Configuration | Driven Rotary Cutting Tool,Punching Tool(V-shape or Circle Shape),Drawing Tool,CCD Camera,Scanner,Cradle(Auto or Normal), Package Box. | |||
Operation Properties | Continuous Cutting with High Efficiency;7*24 with Zero Downtime. | |||
Materials Available For Cutting | Soft fabric, PVC coil floor mat Cutting, printed carpet, leather, soft glass tablecloth, etc. | |||
Supply voltage | AC110V/220V/380V±10%, 50HZ/60HZ, customized. | |||
