PLC Automatic 3000mm High Quality Vertical Glass Sandblasting Machine for High Grade Glass with Competitive Price

Service: Full set after sale services
Certification:CE&ISO
Voltage&Color:Customized
Sales model:Wholesale
Min order:1 set
Power (kw):4.1
Max.Size ( mm):2500X3000mm
Min. Size ( mm):200*500mm
Speed (m2/h):15
Woking Pressure (Mpa):0.6~0.8
Overal size(mm):6050x2000x3500

Quantity:
  • ZY-2500
  • Eworld
  • 8424300000


Basic Info.

Model NO.:

ZY1600/1800/2000 Vertical automatic glass sandblasted machine

Price

USD 8000-12000

Certification:

CE

Type:

Fine finishing

Export Markets:

North America, South America, Eastern Europe, Southeast Asia, Africa, Mid East, Western Europe

Additional Info.

Trademark:

EWORLD

Packing:

Packed in Wooden Case, Seaworthy Package

HS Code:

8424300000

Production Capacity:

10 Sets/ Month

ntroduction:

Product introduction

This is vertical glass sand blasting automatic system. Well known, vertical machine is more convenient and energy saving in the long term.


This machine is half the energy of the horizontal glass sandblasted machine but the vertical one sandblasting speed is 15m2/h, which is slower than the horizonntal glass sandblasted machine.



The machine has 3pcs automatic blasting nozzles,which were automatically applied to blast sand onto the surface of glass as per settled specification,There is one manual blasting nozzle.Automatic and manual can be option.Machine can be design according to customer requirement.



We look forward to offering you the best glass processing machineries with highly economical prices.







Technical parameter:

Total power:

4.1KW

Max. processing size:

1500*3000mm

Min. processing size:

200x500mm

Glass transfer speed:

5 m/min

Nozzle moving speed:

5-25 m/min

Sand blasting speed:

15 m2/h

Suitable working pressure:

0.6MPa~0.8MPa continues

Suitable air pressure power:

2.4 m 3 /min, 15kw

Occupation area: (L X W X H)

6050 x 2000 x 2500mm

Main configuration:

Model No.

ZY-1500

ZY-2000

ZY-2500

Power

4.1(kw)

4.1(kw)

4.1(kw)

Max. Processing Size

1500X3000( mm)

2000X3000( mm)

2500X3000( mm)

Min. Processing Size

200X500 ( mm)

200X500 ( mm)

200X500 ( mm)

Processing Speed

15(m2/h)

15(m2/h)

15(m2/h)

Suitable Woking Pressure

0.6~0.8(Mpa)

0.6~0.8(Mpa)

0.6~0.8(Mpa)

Suitable Air Pressuer Power

2.4m3/min, 15kw

2.4m3/min, 15kw

2.4m3/min, 15kw

Occupation Area LxWxH (mm)

6050x2000x2500

6050x2000x2800

6050x2000x3500


1. the quality (good or bad) of autoclave body itself: there’s no problem  with the pressure of the body, the key is the quality of autoclave door flange and solid and smart of opening  the door or not. Ours is a steel forging of the flange which is the best in china, the door device (as the picture shows ) is not only solid, and easy to adjust, although 1 ton heavier than 1 ton of others, but easy to use, long-term deformation. Adjustment easily switches by a person. Many autoclave door of other manufacturers is deformation after a period of time, brought many troubles to the customers.



2. technology of autoclave is advanced or not: depend on  two aspects, first, energy-saving or not, the second is whether the uniform temperature.



3. water-cooled system and the life of the heating tube: Cooling water pipe leaks and heating tube is short-life, they are a common problem in many autoclave. the cooling system of infrared autoclave adopts finned tube seamless steel pipe and hot-dip zinc processing, non-scaling and  does not rust,the life  is several times  more than ordinary zinc pipe ; infrared heating tube is gold-plated tube, it is not only high efficient, but also long life, there are several times more than the ordinary white quartz heating tube.



4 . Control system: The good control system must be the craft optimization product qualified rate is high, simultaneously the automaticity is high, the operation is simple, cannot operate each kind of pressed key's control system frequently. The infrared autoclave’s control system unified key starts, the entire journey automation, saves the person convenient qualified rate to be high. Has avoided the operators level irregularly to the product quality influence. The practical and feasible technological means will cause the autoclavenot to need to steam spatially will not catch fire.
