Aluminum Window Door CNC Double Head Cutting Saw

Miter Saws work equipment used for cutting. Miter saws are very important for various types of carpentry work. They are used to create the perfect piece to form the elbow and the side frame. Basic miter saw that has a limited capacity cuts. Miter saws that have different types to provide the most versatile cutting options. But, from various types of miter saw, double miter saw is the most applications.

Quantity:
  • LJZ2-CNC-500*4200
  • Eworld
  • 8475291900

Aluminum Window Door CNC Double Head Cutting Saw

 0

Introduction

Miter Saws work equipment used for cutting. Miter saws are very important for various types of carpentry work. They are used to create the perfect piece to form the elbow and the side frame. Basic miter saw that has a limited capacity cuts. Miter saws that have different types to provide the most versatile cutting options. But, from various types of miter saw,  double miter saw is the most applications.

Why should you choose miter double saw? double miter  saw technology uses two saw blades that provide two complementary bevel miter cuts without resetting the head. This feature will obviously vary depending on manufacturer but usually double miter saws provide such benefits as follows:

· Enable the production of continuous production and repetitive high volume

· Provide minute variations in the cutting

· May calibrated scales and fences

· Hold the tweezers,

· Dust filters, connection port or an internal system to collect dust

This tool is an integral component of how double miter  saw equipment will function, whether built by a machine, you can achieve, as bolster precision, smooth cutting, reducing waste of materials, the ability to cut wood, plastic, and various metals. In addition to providing manufacturers May:

· Improved features include semi-automatic

· Locking Security

· Front service access for maintenance and easy changeovers

This Advantage of double miter saw products. You can compare that with another type miter saws. Do not hesitate, to purchase this product, because it will help facilitate your work.

IMG_20180303_162450_副本

01.Control :

The user-friendly control panel installed on the various models ,runs on bearing and allows corrected positioning of the moving cutting heads according to cutting specifications.The work cycle is optimized through creation of the cutting lists thus reducing scrap as well as workpiece loading/unloading times

17

FEATURES:

Two heads with cutting angles 90, 45, 67.5 (22.5) degrees are available.

Automatic feed and cycle run.

Touch screen and NC control system, with high accuracy.

Digital display with high positioning accuracy.

Cushioned pneumatic clamping by push button.

Rack and pinion drive on traveling head with digital positioning.

 IMG_20151130_105219_副本

SPECIFICATIONS:



MODEL

LJZ2-CNC-500*4200

Input voltage

3 P,380V ,50HZ

Input power

4.4Kw/6.5HP

Air pressure

0.5~0.8MPa/ 120psi

Air consumption

200L/min

Motor rotation speed

3400r/min

Cutting length

400~4200mm

Cutting length tolerance

+ 0.005

Cutting angles

90, 45, 67.5 degrees

Cutting angle tolerance

+-0.1

Cutting width

10~130mm

Cutting height

10~300mm

Saw feeding speed

0~3m/min

Saw blade standard

500x4.4x30xZ120

Overall dimensions

6.3x1.7x1.6M
