CNC router For stone industry,stone processing industry,art relief,the advertising industry, decoration industry,
ceramic industry marble granite,jade,bluestone,Blackstone and other kinds of stone,and ceramic,
glass,plexiglass,PVC boards,Aluminum panels,bamboo and other materials.
Quantity: | |
---|---|
CNC Automatic Router
Equipment Features:
1.The overall steel structure welding with tempering aging treatment is strongly undeformed.
Dragon mobile,
fixed working table can arbitrarily processing materials.
2.Adopt Taiwan Linear guide rail. The bearing of the lead guide rail is face to face,
ensure a long-term service life and high accuracy
3.Double-nut automatic disappear gap ball-screw.
4 With constant power motor of spindle, powerful cutting capacity and high efficiency.
5.Break point and break knife continue engraving function, can engrave at any place as you need.
6.Intelligent protection work table: Prevention of table damage caused by misoperation or software
errors.
Intelligent processing of cross-border protection: preventing machinery from colliding
due to that design layout exceeds process range.
7. Advanced Ncstudio control system, control automatically control and finish for 3D multiple levels
processing.
Carrying out rapid and smooth 3D processing, carving or cutting. Offline operation can be realized.
8. Good software compatibility, the CAD/CAM design system like type 3/Artcam/Castmate are
compatible.
9. High power frequency changing water cooled spindle, can process hard materials efficiently,
marble ,granite ,glass,stone,etc
Application area:
For stone industry,stone processing industry,art relief,the advertising industry, decoration industry,
ceramic industry marble granite,jade,bluestone,Blackstone and other kinds of stone,and ceramic,
glass,plexiglass,PVC boards,Aluminum panels,bamboo and other materials.
Model | W1-1325 |
X, Y axis travel | 1300mm*2500mm |
Max. Z axis travel | 260mm |
Max. Feeding height | 260mm |
Table Size | 1480mm*3000mm |
Power of spindle | 3kw water cooling |
Spindle speed | 0-24000rpm |
Working mode | Stepper(Rack-and pinion rotating) |
Max working speed | 25m/min |
Table Structure | seamless cast steel |
Processing precision | ±0.05mm |
Repositioning Precision | ±0.05mm |
Control system | DSP or Ncstudio |
Transmission System | XY Axis advanced rack and pinion,Z Axis ball screw |
Drive motor | Stepper(Optional:Servo) |
XYZ guide rail | linear square guide Rail |
Interface | USB |
Working holding | By fixture |
Working Voltage | AC380/50Hz |
Command language | G code*.u00*.mmg*plt |
Software campatibility | TYP3/Artcam/Castmate/UcancamV9 |
Surroundings for software | Windows 7/98/2000/xp |
