Door and Window Line Gluing Machine

This equipment is for sealing the gap between the windows-door and glass
This equipment adopts well-known CNC system and servo motor, workflow automation control, glue coating process is completed automatically, simple operation, easy to set up, save time and save workers, coating surface uniform and beautiful.
The cost of materials greatly reduced,which use 20L barrel sealant.It is the essential equipment for the door and window automation manufacturing system.
Equipment Advantages:
PLC control system, touch screen man-machine interface, equipment operation is simple and convenient.
The automatic corner system is used to automatically detect the size system. Each corner of the glue can be adjusted separately, around the corner of the glue width, the corner after the glue will not overflow.
Adhesive compactness is higher than industry products. The glue time before and after the corner, the switching glue time can be adjusted.
Special rubber supply and pressure adhesive device, to avoid the traditional supply of glue instability, piezoelectric plate seepage phenomenon.
The size automatic compensation system is used to make up for the effect of glue on the diagonal difference of doors and windows.
Availability:
Quantity:

This equipment is for sealing the gap between the windows-door and glass

This equipment adopts well-known CNC system and servo motor, workflow automation control, glue coating process is completed automatically, simple operation, easy to set up, save time and save workers, coating surface uniform and beautiful.

The cost of materials greatly reduced,which use 20L barrel sealant.It is the essential equipment for the door and window automation manufacturing system.

Equipment Advantages:

PLC control system, touch screen man-machine interface, equipment operation is simple and convenient.

The automatic corner system is used to automatically detect the size system. Each corner of the glue can be adjusted separately, around the corner of the glue width, the corner after the glue will not overflow.

Adhesive compactness is higher than industry products. The glue time before and after the corner, the switching glue time can be adjusted.

Special rubber supply and pressure adhesive device, to avoid the traditional supply of glue instability, piezoelectric plate seepage phenomenon.

The size automatic compensation system is used to make up for the effect of glue on the diagonal difference of doors and windows.

Power2KW
Air pressure0.4-0.8MPa
Max working size

1500×2700mm

Min working size300×300mm
Automatic processing thickness

<100mm

Overall size

3000mm×2000mm×1500mm

Barrel size20L barrel
Working speed90mm/s
One position working size

1.5*2.7m

Overall size

2000*3300
